AKS Cluster Security: Process Linux node updates/reboots using Kured

AKS Cluster Security: Process Linux node updates/reboots using Kured

Facundo Gauna's photo
Facundo Gauna
·

3 min read

Microsoft does download and install security patches automatically and transparently on AKS worker nodes. But, by design it’s your responsibility to restart them. Once you do so, these patches will take effect. So it’s really important that you do so to keep clusters up-date. It’s considered best-practice.

There’s a project called Kured. It’s a daemonset that restarts nodes when it detects new updates. It can integrate with tools like Slack to notify you when a restart happens. You are also able to specify a schedule on when a restart is allowed.

Installing Kured through Helm

There’s a couple of ways to install Kured. My preferred way is through a Helm chart.

helm repo add kured https://weaveworks.github.io/kured
helm install my-release kured/kured

But, realistically you’re going to want to customize it by setting a schedule, alerts, or notifications.

Setting a schedule

You can configure Kured to only restart through certain windows. Useful to avoid downtime during peak hours.

  /usr/bin/kured \
  --reboot-days mon,tue,wed,thu,fri \
  --start-time 5pm \
  --end-time 12am \
  --time-zone America/New_York

Through a Helm chart, this becomes:

helm install kured kured/kured -n [some namespace for kured]\
--set configuration.rebootDays="{mon,tue,wed,thu,fri}" \
--set configuration.startTime=5pm \
--set configuration.endTime=11:59pm \
--set configuration.timeZone=America/New_York

Setting up Slack notifications

A good use of the Slack username is the name of the environment. In this example, I use staging. By the way, here’s some instructions on how to set-up Slack webhooks. Unfortunately, there’s no integration with Microsoft Teams.

helm install kured kured/kured -n [some namespace for kured]\
--set configuration.slackChannel=environments \
--set configuration.slackHookUrl=https://hooks.slack.com/services/blahblah \
--set configuration.slackUsername=staging

Testing Kured

To test on AKS, you’re going to want to follow these instructions to SSH into a worker node.

You’ll have to create a file on the node to indicate to Kured to restart the node. By default, daemon sets check for restarts once an hour. But, each pod on the daemon set offsets from the start time, so you won’t necessarily see all restarts close one after another.

sudo touch /var/run/reboot-required

Kured slack notifications example

Kured + GitOps (Flux)

When using GitOps, the Kubernetes cluster pulls deployments from a Git repository. The Git repository is the source of truth. Therefore, you can declaratively define what Helm charts should be installed in your cluster by committing a file like this one to your manifests repo:

apiVersion: helm.fluxcd.io/v1
kind: HelmRelease
metadata:
  name: kured
  namespace: kured
spec:
  releaseName: kured
  chart:
    repository: https://weaveworks.github.io/kured
    name: kured
    version: 2.2.0
  valuesFrom:
  - secretKeyRef:
      name: slack-secrets
      namespace: kured
      key: values.yaml
      optional: false

In addition, you can use sealed secrets to also define information you don’t necessarily want committed to source control. Then, you can reference this secrets from Flux’s HelmRelease resource through a secretKeyRef.

What about alerting?

In a future posts, I’ll explore how to integrate Kured with Prometheus.
